General Building Information:

Address: 580 Hornby Street, Vancouver, BC   V6C 3B6

Legal Description: Lot 29, Block 31, District Lot 541, Plan 210

Constructed: 1986

Typical Floor Area: 6,819 square feet

Total Building Area: Approximately 54,055 square feet

Parking: 24 underground stalls and 8 outside stalls

Elevators: 2 passenger, 350 feet per minute

Floors: 9 + basement

Mechanical: Typical floors has individual floor fans complete with 6 internal and 6 perimeter variable air volume boxes.

Electrical: Typical office lighting consists of 347volt 1x 4 foot double tube fluorescent light fixtures complete with T-8 lamps and electronic ballasts.  Motion Sensors control lighting in the washrooms, aiding energy conservation.

Emergency Power: Should a power failure occur the building uses a diesel powered generator which will supply power to all exit signs, stairwell lights, some corridor lights and to all fire alarm systems. All elevators will return to the ground floor and one elevator can be used for fire service.

Life Safety System: The building has a single stage supervised fire alarm system and is sprinklered throughout. Each floor contains multiple pull stations, signal appliances, automatic detectors, public address speakers and firefighters’ telephones.

Construction Type: The building is constructed primarily of concrete, steel and glass.

Roof: Double layer torchdown system.
